Door closer TS 4000 E with link arm for doors with up to 1400 mm leaf widths
Operating voltage 24 V DC
Closing force, infinitely adjustable EN 1-6
End stop adjusted using the arm, closing speed can also be adjusted
Optical closing force display
Hold-open range 80°-180° (electro hydraulic)
Low power consumption
Can be used for right and left swing doors without conversion
For fire and smoke protection doors. Uninsulated steel fire door can only have the surface applied door closer mounted on the known fire side of the door (the side of the door that faces the risk of fire), this assessment to be undertaken and defined by building control.
